Item Information:
8 Port electrical fuse block, wires can be screwed down on to the terminal.
Use on cars, boats, and other universal terminal block uses.
Uses standard ATO/ATC/APR fuse type
Split single positive DC line (red) into multiple fused inputs, allows 8 way split with this fuse block
Weather resistant sticker label included to label each port to indicate powering unit.
Includes 10 premium Littelfuse Fuses:
5A x 2
7.5A x 2
10A x 2
15A x 2
20A x 2
Features:
- 8 Port / 8 Way Fuse Terminals from Single Line Input.
- Widely used in airplane, subway, bus, ship, tanker, modified car, eco-car, etc.
- Can be installed in circuit
- Max. current: 25AMP per Port, Up to 32V
- Standard ATO / ATC / APR fuse types
- Clear plastic Cover – Vibration Resistant & Snap Fitting
- Two mounting holes
- Includes weather resistant label to indicate port use
| Weight | 2 oz |
|---|---|
| Dimensions | 6 × 4 × 1 in |
| Color | Black |
